StarTech.com 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD
Sale price
$205.80
Regular price
$262.69
Skip to product information
Connect and hot swap four 3.5in SATA III or SAS II hard drives to your computer system in three 5.25” bays, with support for transfer speeds up to 6 Gbps
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
StarTech.com 4 Bay Aluminum Trayless Hot Swap Mobile Rack Backplane for 3.5in SAS II/SATA III - 6 Gbps HDD
Sale price
$205.80
Regular price
$262.69
HSB4SATSASBA
The HSB4SATSASBA Removable 4-drive Backplane makes inserting and removing drives fast and easy, by turning three 5.25" bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD).
For added versatility, the hot swap bay can interface with SATA I/II/III and SAS I/II hard drives -- an ideal solution for enterprise system applications.
For a quick and secure method of installing and removing drives, the backplane features ejection levers and a key-lock design. To help prevent drive failure, the bay provides drive cooling with a built-in fan and excellent heat dissipation with a vented aluminum enclosure.
The HSB4SATSASBA is backed by a StarTech.com 2-year warranty and free lifetime technical support.
- INCREASED PRODUCTIVITY: The mobile rack backplane for 3.5in SAS II/SATA III turns three 5.25in bays into a hot-swappable interface for up to four 3.5” SATA or SAS hard drives (HDD)
- MAXIMUM COMPATIBILITY: The hot swap backplane for 3.5in SAS II/SATA III can interface with SATA I/II/III and SAS I/II hard drives, an ideal solution for enterprise system applications; Power and status LEDs for each bay
- EASY TO USE: For a quick and secure method of installing and removing drives, this trayless hot swap mobile rack backplane features individual ejection levers for each bay and a key-lock design (includes two keys)
- MAINTAIN OPTIMAL TEMPERATURE: To help prevent drive failure, the 4-drive hot swap backplane features a vented solid aluminum enclosure that provides excellent heat dissipation in addition to a built-in fan with speed control; UL VO flammability rated
- THE IT PRO'S CHOICE: Designed and built for IT professionals, this 4-Bay hard drive backplane is backed for 2 years, including free lifetime 24/5 multi-lingual technical assistance
Specifications
Features
| Product colour | Black |
| Material | Aluminium |
| Hot-swap | Yes |
| Number of fans | 1 fan(s) |
| Fan diameter | 7 cm |
| Data transfer rate | 6 Gbit/s |
| LED indicators | Activity, Power |
| Key lock | Yes |
| Certification | CE, FCC |
Ports & interfaces
| External SATA ports quantity | 4 |
Weight & dimensions
| Width | 145 mm |
| Depth | 197 mm |
| Height | 124 mm |
| Weight | 1.3 kg |
Packaging data
| Package width | 254 mm |
| Package depth | 169 mm |
| Package height | 185 mm |
| Package weight | 1.59 kg |
Packaging content
| Cables included | SATA |
| Screws included | Yes |
| Manual | Yes |
Operational conditions
| Storage temperature (T-T) | -20 - 65 °C |
| Operating temperature (T-T) | 0 - 55 °C |
| Operating relative humidity (H-H) | 5 - 85% |
Technical details
| Compliance certificates | RoHS |
Logistics data
| Products per master (outer) case | 6 pc(s) |
| Master (outer) case width | 531 mm |
| Master (outer) case length | 392 mm |
| Master (outer) case height | 288 mm |
| Harmonized System (HS) code | 84733080 |
